Tek 468 475 475A 485 service/op 7 volumes manuals set

For Sale: Tek 468 475 475A 485 service/op 7 volumes manuals set


Subject Tek 468 475 475A 485 service/op 7 volumes manuals set
Ad is submitted by poster: Tektronix 468 475 475A 485 Service and Operating Manuals in PDF on CD
For page samples from this specific set (4xxSet), click HERE.
These PDF manuals cover the Tektronix 468, 475, 475A and 485 Oscilloscopes. Included are the full service manual (both volumes; volume one does contain a good operations section) for the 468, plus the 475A service manual, plus the 475 Service Manual for serial numbers B0250000 and higher, and the Tek 485 Service Manual, which also contains a good operations section. Separate Operating Manuals are included for the 475, one including DM44 Operations and the other including DM40/43 Operations. They are all scanned from the original manufacturer's paper manuals.
The pages are readable and the quality will be acceptable to engineers and technicians who need service and operations information. Manual collectors and the like do need to look elsewhere, as I do not remove notations and such if they are present (that notation might be valuable to you if you're working on a unit!) None of these are "very high resolution" scans as defined in our "dual resolution" offerings, although they're readable and have been used to repair or maintain a lot of units.
Here are specific notes as to readability. This applies only to this 4xx set, and not to any other PDF manual(s) we offer:
468_vol1.pdf - Schematic values sometimes difficult to read, otherwise fair.
468_vol2.pdf - Schematic values sometimes difficult to read, otherwise fair.
475a.pdf - Tek 475A Service Manual with Operations - readable throughout.
tek475op.pdf - Tek 475 Operating Manual with DM44 Operations included - readable throughout.
tek475sm.pdf - Tek 475 Service Man'l w/Ops Sections, s/n B0250000 and up - readable throughout.
tek485.pdf - Tek 485 Service manual with Operations - pretty good!
465475op.pdf - Tek 475 Operating Manual with DM40/DM43 Operations included - readable, fair at best. Also has 465 op manual in same document.
To compete with the folks trying to "market" you out of your money with tricks like free download manual enhanced "volume counts", we probably shouldn't even include the lesser-quality manuals, as the 475, 475A and 485 manuals sell perfectly well without them. We'll continue to include them, but please remember they're essentially freebies and the purchase price is based solely on the 485 manual, which is quite good quality, other than that the foldout pages are full-size 11x17" instead of pre-sectioned into 8-1/2x11" sheets, so most folks will have to do some extra work in order to print them.

repair--parts.com bears NO responsibility for this ad. Please report ads that do not follow our rules (on front page). Posted By: Andre Duke
Contact: Andre-Duke@repair--parts.com (Andre Duke) (this is a temporary forwarding address).
