Lin act pneumatic 250 psi air cyl low rider tilt bed

For Sale: Lin act pneumatic 250 psi air cyl low rider tilt bed


Subject Lin act pneumatic 250 psi air cyl low rider tilt bed
Ad is submitted by poster: See my store for other industrial items.
· Construction: Aluminum, Repairable, Square head/cap, Extruded tube
· Mounting Styles: 16 Standard.
· Bore Sizes: 1 1/4" through 8"
· Piston Rod Diameter: 1/2" to 1 3/4"
· Rod Ends: Three standard choices, specials to order
· Strokes: Available in any practical length up to 100 inches
· Cushions: Optional at either or both ends
· Bumpers: Optional at either or both ends
· Nominal Pressure: Up to 250 psi pneumatic service
· Standard Fluid: Filtered, lubricated or non-lubricated air
· Standard Temperature: -10°F to +165°F
· Additional Information: * Rod Gland Assembly - Can be removed without cylinder disassembly for ease of maintenance. * Inboard Bearing Surface - Assures positive lubrication of the gland bearing. * Piston Rod Lipseal/Wiper - Self - compensating to keep pressure in and contamination out. * Adjustable Check - Seal Cushions - Effective end of stroke cushioning and fast stroke reversal. * Captive Cushion Adjustment - Needle adjusting screw can't be backed out too far. * Aluminum Heads and Caps - Lightweight design is anodized for maximum corrosion resistance. * Cylinder Body - Clean, extruded design limits areas for contamination to accumulate.

repair--parts.com bears NO responsibility for this ad. Please report ads that do not follow our rules (on front page). Posted By: Sonja Luna
Contact: sonja_luna@repair--parts.com (Sonja Luna) (this is a temporary forwarding address).
