50000Lb WELDING POSITIONER, Aronson GE500 Var
50000Lb WELDING POSITIONER, Aronson GE500 Var
50,000 LB KOIKE-ARONSON GEARED ELEVATED POSITIONER
MODEL GE500CS S/N 7642 NEW 1976
TABLE WEIGHT @ 12" CG HEIGHT .................. 50,000 LBS
TABLE WEIGHT @ 18" CG HEIGHT .................. 39,000 LBS
TABLE WEIGHT @ 24" CG HEIGHT .................. 32,000 LBS
TABLE WEIGHT @ 30" CG HEIGHT .................. 27,000 LBS
TABLE WEIGHT @ 36" CG HEIGHT .................. 23,400 LBS
TABLE WEIGHT @ 42" CG HEIGHT .................. 20,600 LBS
TABLE WEIGHT @ 48" CG HEIGHT .................. 18,500 LBS
TABLE WEIGHT @ 54" CG HEIGHT .................. 16,700 LBS
TABLE WEIGHT @ 60" CG HEIGHT .................. 15,200 LBS
TABLE WEIGHT @ 66" CG HEIGHT .................. 14,000 LBS
TABLE WEIGHT @ 72" CG HEIGHT .................. 13,000 LBS
ROTATION LOAD TORQUE PER INCH ................. 600,000 LBS.
TABLE HEIGHT, MAXIMUM ......................... 92-1/2"
TABLE HEIGHT, MINIMUM ......................... 59-1/2"
TABLE SIZE .................................... 84" X 84"
MAXIMUM CLAMPING DIAMETER ..................... 112"
NUMBER OF SLOTS x WIDTH ....................... 4 x 1-5/16"
TABLE THICKNESS ............................... 2-3/4"
PILOT HOLE DIAMETER ........................... 12.253"
PILOT HOLE DEPTH .............................. 1-13/16"
INHERENT OVERHANG ............................. 8-3/4"
TILT 135 DEG. IN .............................. 67 SECONDS
TILT BRAKE MOTOR HP ........................... 15
ELEVATION LIFT AT CONSTANT SPEED .............. 20 IPM
ELEVATION BRAKE MOTOR HP ...................... 20
HORIZ. AXIS HEIGHT MINIMUM .................... 50-3/4"
HORIZ. AXIS HEIGHT MAXIMUM .................... 83-3/4"
GUARANTEED WELD CURRENT CONDUCTION ............ 3000 AMPS
- SIMULTANEOUS TABLE TILT AND ROTATION
- EASY ACCESS TO ANY SECTION OF WELDMENT
- MULTIPLE POST GEARED ELEVATION WITH RACK TEETH IN POSTS
AND PINIONS ARE CARRIED ON BEARINGS IN CHASSIS SIDE PLATES
- LIFT PINIONS RUN IN UNISON, THEREFORE ANY FAILURE WILL
DIMENSIONS: 94" X 106-1/2" X 134-3/4"
Machine Location: HARRISON, NJ
Click Here For More Aronson Machines
Click Here For More Welding Equipment - WELDING POSITIONERS(s)
Call Rick at (***) 873-6224 ext 7560
Call Alex at (***) 873-6224 ext 7613
Finance This Equipment For Your Business - Click Here
Finance Equipment For Your Business - Click Here
* Machinery Values is one of the world's largest machinery dealers, in business since 1971.
* New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines.
* Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this.
